| Type | BZYX68-RGW | ||||||
Functional status | Navigation lights | Anchor light | Warning light | ||||
Indicator light | Distress light | Emergency light | Obstruction light | ||||
Light color and angle | 112.5° red & 112.5° green & 135° white | 112.5° red & 112.5° green | 360°white | 360°white | 360°white | 360°white | white |
Luminous type | Normal | Normal | Normal | stroboscopic | SOS | Normal | Fourstroboscopic |
Max viewing distance | Normal>1nmile | Normal>1nmile | Normal>2nmile | Flashing >3nmile | Flashing >3nmile | Normal>2nmile | Flashing >3nmile |
Working Status | >12h | >15h | >12h | >150h | >12h | >12h | >150h |
Working mode | 2nd Function | 3rd Function | 6th Function | 4th Function | 5th Function | 6th Function | 1st Function |
Start method | Wireless remote control & Manual switch | Light sensitive | |||||
Power supply | Built-in lithium battery | ||||||
Light source | High Efficient LED | ||||||
Remote control distance | More than 20m | ||||||
Battery charging energy | Solar | ||||||
Max wind resistance level | 12 wind | ||||||
Working temperature | -30~+65 ℃ (-22 ~+149 ℉ ) | ||||||
Dimension | Main body : 115*99.1mm | ||||||
Weight | Lamp and wireless remote : 250g Bracket and screws : 120g | ||||||
Power cord length | 1m | ||||||
Ingress Protection | IP67 | ||||||
Performance | UV-resistant, Fire-resistant, Oil-resistant, Mould-proof, Corrosion-proof Approval | ||||||
Standard | CIOREG72, EN14744, IEC60945 | ||||||
Type | BZYX68-R | BZYX68-Y | BZYX68-B | BZYX68-G | BZYX68-W |
Light Color | 360°red & 360°white | 360°yellow & 360°white | 360°blue & 360°white | 360°Green & 360°white | 360°white |
Max. Visual Distance | Red light>1.5n mile White light>2.0n mile | Yellow light>1n mile White light>2.0n mile | Blue light>0.5n mile White light>2.0n mile | Green light>2.n mile White light>2.0n mile | White light>2.0n mile |
Max. Continuous Working Time | Flashing>300h SOS>20h Steady>12h | Flashing>300h SOS>20h Steady>12h | Flashing>150h SOS>20h Steady>12h | Flashing>150h SOS>20h Steady>12h | Flashing>150h SOS>20h Steady>12h |
1st Function | (Auto. Light sensor switch) Red gradual flashing light | (Auto. Light sensor switch) Yellow gradual flashing light | (Auto. Light sensor switch) Blue flashing light | (Auto. Light sensor switch) Green flashing light | (Auto. Light sensor switch) White flashing light |
2nd Function | Red single flashing light | Yellow single flashing light | Blue single flashing light | Green single flashing light | White single flashing light |
3rd Function | Red steady light | Yellow steady light | Blue steady light | Green steady light | White steady light |
4th Function | White SOS light | White SOS light | White SOS light | White SOS light | White SOS light |
5th Function | White steady light | White steady light | White steady light | White steady light | White steady light |
6th Function | OFF | OFF | OFF | OFF | OFF |
Light Source | LED | ||||
Activation of the first function | Automatic light sensor controlling | ||||
Activation of the other functions | Manual switch and wireless remoteRemote | ||||
Remote-controlled Distance | ＞20m | ||||
Power Source | Built-in lithium battery | ||||
Recharging Energy | Solar power (take about 3days / 24hrs under strong sunlight to fully recharge empty battery) | ||||
Max. Resistance Wind-force | 12wind | ||||
Storing and Working Temperature | -30~+65℃(-22 ~+149℉) | ||||
Dimension | Main body:115*73.2mm | ||||
Weight | Light and wireless remote: 225g Bracket and screws:120gIngress | ||||
Ingress Protection | IP67 | ||||
Performance | UV-resistant, Fire-resistant, Oil-resistant, Mould-proof, Corrosion-proofApproval | ||||
Standard | CE& FCC | ||||
